CONTINUOUS AMBIENT AIR QUALITY MONITORING SYSTEMS (CAAQMS)
INTRODUCTION
The starting point for making any city Sustainable, Safe & Secure is by real time monitoring and surveying at right place.

These acts are required to be monitored and controlled. Real time monitoring by sensors in right place will assist in predicting and controlling. Thus, enabling the remote detector to gather relevant information for making the city ready for any type threats or any likely event of disaster.
FUNCTIONAL OBJECTIVES
CATS introduces cutting edge technology wherein a single photonic system with an appropriate laser source is used for monitoring all parameters of ATMOSPHERE, EARTH & OCEAN. With more than 20 years of diligent R&D, CATS has developed a cutting edge multipurpose sensor by using single laser (light) as medium for multifunctional applications. Accurate qualitative and quantitative data is collected in real time using a single laser source as a function of time and space.

Sensor's Light can travel to far away distance of 5km hence monitoring is possible from far away distance. Laser sensors are at the fractional cost to their conventional equivalent. The photonic system collects a 1000 data points per mili second. CATS is the only company providing single laser Sensor that can monitor and records various Force Movement, Pollution, Weather, Acceleration, Displacements, Flow, Position, Sound, Ground Vibration etc.
ATTRIBUTES
The sensitivity and accuracy of the monitored parameters are very high compared to conventional sensor measurements. The multifarious advantages of the systems include smaller time responses, higher accuracies, one system to measure a host of parameters in the time, frequency and spatial domains and the freedom from many known constraints associated with conventional sensors. All the data is seamlessly integrated, distinguished and stored on Big Data. This will assist in making geospatial, predictive, prescriptive and descriptive analytics on continual and long-term basis.
CATS PHOTONIC SENSORS CAN CREATE A VIRTUAL SHIELD FOR A CITY
CATS sensors are installed based on the environment, infrastructure, population and span of city. Few sensors installation will cover complete city. CATS Array of Things will provide real time, geo spatial data by interacting with entities like Environment, Infrastructure / Transportation fitness, Security, Surveillance and Individual Health. Integration with BIG DATA will provide new actionable insights, enabling everyone to harness information for a better integrated SMART City.
ENABLER
  • Comprehensively mitigate gaps in current solutions & future ready i.e. redundancy proof with low capital cost and low operating cost.
  • Have vast application potential - A Laser can collect 1000 data points per millisecond in real time.
  • Are naturally amenable very high accuracy & reliability. Easy to Use.
  • Laser beam as a source can travel to the target whereas with most sensors the target must be brought to the sensor.
  • Can easily travel to inaccessible target areas. Replaces multiple sensors.
FEATURES
Features Benefits
Continuous monitoring (CAAQMMS)

AUM is the only continuous monitoring system which can be easily set up. Other methods provide either a snapshot of pollutants or are prone to data loss due primarily to weather (humidity). Monitors combination of gases. The system can also be customized as per user needs.

  • CO2, CO, H/C's, H2S, NOx, O3, Sox, NH3, and other oxidants.
  • Volatile Organic Compounds (VOC) - such as formaldehyde, benzene, methylene chloride and perchloroethylene, O-Xylene, p-Xylene, Et-Benzene, Benzene, Toulene
Meteorological Measurement

Measures meteorological factors like temperature, humidity, wind parameters (speed , direction, pressure, velocity), precipitation that show how pollutants are transferred from source to recipient.
Sensing Area coverage

Area covered by AUM is 10mm to 5 Km in radius. The unit can be rotated3600. Data of air can be collected vertically as well as horizontally at distance of every 100mm to 5km as required. The laser beam travels to the targeted area / source of pollutants. With few nos. of installation complete city can be monitored for pollutants and weather conditions.

Continuous monitoring under all weather conditions without data loss

Photonic sensing technology are not affected by weather conditions such as humidity, rain, snow, morning dew or even conditions such as dust or aerosols, thus ensuring continuous monitoring.

Easy to set up and maintain

AUM is field tested and rugged. It is powered with a small battery or on AC power and uses less than 100 watts of power. When ready to use, the instrument starts working immediately (no warm up required).

APPLICATIONS
  • Smart City
  • Industry
